Model: 1200
Drilling diameter: 5-60mm
Processing glass thickness: 3-19mm
Drilling stroke: 5-1100mm
Work platform height: 900mm
Drilling speed: ≤ 7-15s
Automatic drilling quantity: 20pcs
Batch product hole position deviation: ≤± 0.13mm
Processing glass size: 750x1100mm
Power: 6kw
Weight: 1500kg
Dimensions: 2780x2800x1800mm
Drilling method: first drill the lower hole, then drill the upper hole
Feature And Function
The X-axis and Y-axis are equipped with servo drive, making the hole position more precise (positive and negative tolerances can be maintained within 15 threads).
The work program is controlled by a PLC program, which can remember multiple sets of drawing data, and can be replaced, retrieved, and easily converted from multiple products at any time, saving time.
The processing table can be infinitely extended and directly connected to the production line, making it convenient for cross equipment integration.
The requirements for operators are extremely low and can be completed with just one click.
It has continuous automatic function and only requires loading and unloading. The rest of the work is automatically completed.
